Product information
***WiNet module and 3-phase meter are included in delivery***
The powerful combination with the proven Sungrow hybrid inverters creates the ideal conditions for all applications. Suitable storage systems are available, from the company's own SBR series to Axitec, Pylontech, and BYD. With power classes from 5 to 10 kW, there is a suitable device for every home. By connecting up to five systems in parallel, applications in the small commercial sector are also conceivable. And the latest generation of hybrid devices can now also be combined with Sungrow EV chargers.
Product advantages:
• Suitable for high-performance modules
• Compatible with the Sungrow EV Charger
• Emergency power operation via backup connection
• AC + DC surge protection type 2 integrated
• Up to 5 systems in parallel operation
Product features:
• AC power: 10.0 kW
• Number of MPPTs: 2
• DC input current: 13.5A (MPPT 1), 27.0A (MPPT 2)
• AC connection: 400V, 3-phase
• Communication: Wifi, LAN, RS485, CAN, 4 x DI (FRE), 1 x DO
• Protection class: IP65
• Cooling: passive
• Dimensions: 540 x 470 x 170 mm (L x W x H)
• Weight: 27.0 kg
• Warranty: 10 years
| Topology: | Transformers |
| Interface 1: | RS485 |
| Feed-in phases: | 3 |
| Boost converter: | Yes |
| Max. efficiency (%): | 98.40 |
| European efficiency (%): | 97.90 |
| Number of MPP trackers (pcs): | 2 |
| Arc Fault Circuit Interrupters: | no |
| Interface 2: | Ethernet |
| Housing protection class: | IP65 |
| Max. input voltage DC (V): | 1,000.00 |
| Battery coupling: | AC/DC |
| Max. AC power (kVA): | 10.00 |
| AC rated power (kW): | 10.00 |
| Max. DC connected load (kWp): | 15.00 |
| Max. number of string inputs (pcs): | 3 |
| Display: | without display |
| Max. total input current (A): | 40.50 |
| Min. MPP input voltage (V): | 200.00 |
| Max. MPP input voltage (V): | 250.00 |
This information will be added shortly.
